Xinyun Jrt Roll Automatic Maxi Roll Paper Cutting Band Saw Machine Max 300mm Length 15KW

Xinyun Jrt Roll Automatic Maxi Roll Paper Cutting Band Saw Machine Max 300mm Length 15KW
Xinyun Jrt Roll Automatic Maxi Roll Paper Cutting Band Saw Machine Max 300mm Length 15KW Xinyun Jrt Roll Automatic Maxi Roll Paper Cutting Band Saw Machine Max 300mm Length 15KW Xinyun Jrt Roll Automatic Maxi Roll Paper Cutting Band Saw Machine Max 300mm Length 15KW Xinyun Jrt Roll Automatic Maxi Roll Paper Cutting Band Saw Machine Max 300mm Length 15KW Xinyun Jrt Roll Automatic Maxi Roll Paper Cutting Band Saw Machine Max 300mm Length 15KW Xinyun Jrt Roll Automatic Maxi Roll Paper Cutting Band Saw Machine Max 300mm Length 15KW

Large Image :  Xinyun Jrt Roll Automatic Maxi Roll Paper Cutting Band Saw Machine Max 300mm Length 15KW Get Best Price

Product Details:
Place of Origin: Fujian
Brand Name: Xinyun
Certification: ce
Model Number: XY-AI-500
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: $22000-25000/SET
Packaging Details: Maxi roll band saw cutting machine will be packed by wooden pallet.
Delivery Time: 60DAYS
Payment Terms: T/T, L/C, Western Union
Supply Ability: 100sets/year
Detailed Product Description
Type: Paper Cutting Machine Cutting Length: Max 300mm
Function: Paper Cutting Cutting Diameter: 150-300mm
Cutting Speed: 15-20rolls/min Voltage: Based Your Factory Power
Warranty: 1 Year Color: White
High Light:

Jrt Roll Automatic Metal Cutting Band Saw Machine

,

Xinyun automatic metal cutting band saw machine

,

300mm Length heavy paper cutting machine

Automatic Jrt Jumbo Roll Maxi Roll Tissue Paper Band Saw Cutting Machine XY-AI-500

Product Application
The equipment is the latest research and development which is the extension of the company with the current market situation.
Using PLC program control, big screen true color human﹣computer interface. The precise servo control feed length, electromechanical integration control and other international advanced technology con automatically detect each key action, has good fault information prompt system, make the whole production line achieving the best working state.



Product Specifications
Cutting speed 15-30cuts/minute
Cutting channel single channel
Cutting blade band saw blade
Cutting blade size 5180*90*1.2
Log length Max. 2200m Or Max. 2850mm
Tolerance ±2mm
Cutting length Max. 280mm
Cutting diameter 150-300mm(Adjustable 150-200, 200-300)
Thickness of paper core Max.3 mm
Power supply 15KW 3 phase 4line 380V 50HZ
Machine weight 2700KG
Overall size of machine 4600*2350*2200mm(2.2m jumbo roll)
5300*2350*2200mm (2.2-2.85m jumbo roll)
Separated size Paper storage: 1500*1650*900mm( 2-4 logs )
Main machine: 4600*1700*2200mm(2.2m jumbo roll)
Paper storage: 1700*1650*900mm ( 2-4 logs )
Main machine: 5300*1700*2000mm(2.2-3m j
umbo roll)


Video Link: https://youtu.be/4jasCm1xL7g

https://youtu.be/YVRAW_Uks18

Xinyun Jrt Roll Automatic Maxi Roll Paper Cutting Band Saw Machine Max 300mm Length 15KW 0

Xinyun Jrt Roll Automatic Maxi Roll Paper Cutting Band Saw Machine Max 300mm Length 15KW 1
Xinyun Jrt Roll Automatic Maxi Roll Paper Cutting Band Saw Machine Max 300mm Length 15KW 2



Company information

Fujian Xinyun Machinery Development Co.,Ltd is good at Paper Converting Machinery Manufacture.Professional supplier of:
1) Toilet Paper Machine (1.2m--2.8m width of parent roll, Customize Service)
2) Roll Kitchen Paper Towel Machine (1.2m--2.8m width of parent roll, Customize Service)
3) Facial Tissue Machine (2-8 output lanes)
4 )Napkin Paper machine(L-fold, 1/4-fold, 1/6-fold, 1/8-fold and other multi-fold type)
5) Hand Towel Paper Machine(C-fold, V-fold and N/Z fold type)
6) Pocket Tissue Machine(mini and standard size)
7) All kinds of Tissue Paper Cutting and Packing Machine
8) Another Household Paper Equipments and Production Line.
